Window Schüco AWS 75 SI Saving energy and generating energy have become central themes for architecture, inextricably linked with the topics of security, automation and design.
Above all, the Schüco Window AWS 75.SI has become an integral part of this development.
In conjunction with the concealed Schüco TipTronic fittings, the energy-saving potential of building automation can be fully exploited.

Schüco Window AWS 75.SI optimised thermal insulation standard for aluminium windows.
Whether as an energy-efficient high-end solution with triple glazing or an energy-efficient, economical construction with double glazing (Ug = 1.1 W/m²K)
and warm edge spacers, Schüco window systems meet the future threshold value for EnEV 2009 of Uw =1.3 W/m²K.

• Outstanding thermal insulation for basic depth of 75 mm: Uf value of 1.3 W/m²K (face
width of 117 mm)
• Uw = 1.3 W/m²K with double glazing, Uw • Optimised centre gasket with fin and glazing rebate gasket with foam core
• Glazing rebate insulation has new geometry for improved thermal insulation and simpler production capacity
• Extended range of profiles for diverse solutions
• Available in the RL = Residential Line and SL = Soft Line design series
• Compatible with Schüco Doors ADS and ADS HD

Window Schüco AWS 75 BS SI block system combine the proven benefits of block windows – elegant design and the largest possible transparency – with the highest thermal insulation requirements.

• Excellent thermal insulation for a basic depth of 75 mm: Uf value of 1.4 W/m²K (face width of 89 mm) Uw = 1.3 W/m²K with double glazing
• Uw • New bar material in the vent, optimised centre gasket with fin, and glazing rebate gaskets with foam core are all features of excellent thermal insulation
• Very narrow face widths from 67 mm due to concealed glazing beads
• Schüco TipTronic can be used
• Comprehensive profi le range with mullion face widths up to 44 mm, insert outer frames of up to 51 mm, double vents and vent sash bars

Window Schüco AWS 70.HI The high quality window system with a comprehensive range of solutions.
The AWS 70.HI offers a comprehensive range of solutions for special design requirements. The rounded SL vent contour in conjunction with the appropriate glazing bead is an attractive solution for softer lines.

The Schüco Window AWS 70 ST.HI system, with its very narrow steel contour, is ideal both for refurbishing old steel windows or fi tting new homes with attractive steel-look windows.

• Improved thermal insulation with a basic depth of 70 mm: Uf values of 1.6 W/m²K (face width 117 mm)
• Also available as flush-fitted vent, outward-opening vent or as crank-operated turn/tilt solution for large, heavy units
• Wide range of profiles including the design systems: Schüco AWS 70 RL.HI (Residential Line), Schüco AWS 70 SL.HI (Soft Line) and Schüco AWS 70 ST.HI (Steel contour)
• Compatible with the Schüco ADS and ADS HD door range

Window Schüco AWS 70 BS.HI Slimline block construction for a high-quality appearance.

• Good thermal insulation with a basic depth of 70 mm: Uf values of 1.9 W/m²K (face width 89 mm)
• Also available as flush-fitted vent
• Very narrow face widths from 67 mm due to concealed glazing beads
• Enlarged insulation zone with foam-filled insulating bars
• Comprehensive profile range with mullion face widths of up to 44 mm, double vents and sash bars

Schüco Window AWS 65 The basic series with comprehensive range to enhance design ideas.

• Improved thermal insulation with a basic depth of 65 mm: Uf values of 2.2 W/m²K (face width 117 mm)
• Wide selection of profiles including the design systems: Schüco Window AWS 65 RL, Schüco Window AWS 65 SL and Schüco Window AWS 65 MC (multi-contour)
• Matches the Schüco ADS and ADS HD door range
• Also, for the Italian window market, there are the design systems Schüco Window AWS 65 RD (Residential Design) and Schüco AWS 65 SD (Soft Design)
• Available as flush-fitted or outward-opening vent

Window Schüco AWS 65 BS The ideal solution for block window constructions with a basic depth of 65 mm.

• Good thermal insulation with a basic depth of 65 mm: Uf values of 2.2 W/m²K (face width 89 mm)
• Very narrow face widths from 67 mm due to concealed glazing beads
• Comprehensive profi le range with mullion face widths of up to 44 mm, double vents and sash bars

Window Schüco AWS 50.NI Non-insulated window system with 50 mm basic depth for interiors.

• The appearance of the buildingis consistent inside and outside, as the face widths are identical with those of the thermally insulated window systems
• Solutions for outward-opening vents or horizontal/vertical pivot windows
• Also available as flush-fitted vent
• Very narrow face widths from 74 mm
• Glazing thicknesses of 4 – 42 mm can be used
• Vent weight up to 160 kg
Facade Schüco FW 50+ SI With innovative isolator technology, the newly developed SI solution (Super Insulation) for the FW 50+ system is a leap into the next generation of
thermally insulated façade systems.

• Optimisation of thermal insulation due to the new isolator concept with Uf values of up to 0.8 W/m²K including screw influence
• Reflective surfaces on the insulating tape, the aluminium pressure plate and on the plastic pressure plate reduce energy losses through thermal radiation
• Possible to support large glass loads of up to 400 kg per transom for FW 50+ and 600 kg for FW 60+
• Triple glazing with up to 64 mm glass thickness possible due to the new glazing support
• Due to its shape, the new isolator ensures the screw guide is secure in the screw port, even for large glass thicknesses
• Integration of the SI components in the FW 50+ system with full compatibility to all existing system articles
• System solution for façade integrated photovoltaics ensures a secure and economical fabrication process for synergy façades
• Compliance with the requirements of ENEV 2009 for standard façade constructions with double glazing
• High energy-saving potential for the investor due to the high savings in weight and therefore material compared to triple glazing
• A variety of products with different profile depths and a comprehensive range of cover caps to meet any architectural and construction requirement

Facade Schüco FW 50+ The tried-and-tested FW 50+ and FW 60+ systems allow façades and skylights of very varied design to be constructed efficiently and reliably.

• From SI façades with maximum thermal insulation through to standard thermal insulation, the FW 50+ and FW 60+ systems offer the right solution for every scenario and all climate regions
• A large range of cover caps offers outstanding design variety for the most varied of façade styles
• Bullet resistance, burglar resistance and blast resistance options
• Can also be used as a fire-resistant façade (.BF)
• Electrical cables are concealed within the façade system, but can be accessed for inspection
